A new genus and species of surgeon fish (Perciformes, Acanthuridae) from the Oligocene of Kanton Glarus, Switzerland
Swiss Journal of Palaeontology volume 130, pages 203–216 (2011)
The new genus and species of surgeon fish, Glarithurus friedmani (Acanthuridae), from the Lower Oligocene (Rupelian) of Kanton Glarus, Switzerland, differs from all other acanthurid fishes, fossil and extant, by having a single anal-fin basal pterygiophore situated in the first interhaemal space, versus two or more such pterygiophores in all other taxa. The new taxon is based upon a 29-mm SL acronurus stage specimen that probably had already settled onto a benthic substrate from its pelagic larval stage and begun its transformation into a juvenile. It has a scalpel-like dermal spine on the caudal peduncle and a crest on the hyomandibular, which are derived characters that establish it as a member of the clade of higher acanthurins. Within that clade, it is unique because of the great depth of its basipterygium at the subpelvic keel.
Large schools of acanthurid surgeon fishes browsing on algae are a prominent component of modern coral reef ecosystems and their surrounding flats in tropical seas worldwide. Six genera and about 80 species of surgeon fishes are alive today (Randall 1955; Tyler 1970; Nelson 2006). Using the same level of morphological differentiation that has been used to distinguish the six Recent genera from one another, 15 genera of fossil acanthurids (in the Acanthurinae and Nasinae, which have both fossil and extant taxa) have been recognized from the Eocene to the Miocene (Tyler and Bannikov 2000), and two other genera represent distinct subfamilies of Eocene acanthurids (Padovathurinae and Gazolaichthyinae, Tyler 2005a, 2005b). Most of the fossil acanthurids are known from the Middle Eocene of the classic fossil locality of Monte Bolca in northern Italy, which is by far the richest coral-reef-associated ichthyofauna of Eocene age in the world. The 11 genera of acanthurin and nasin acanthurids known just from Monte Bolca are almost twice as morphologically diverse as is this dominant worldwide group of coral-reef fishes today, and the two taxa of padovathurin and gazolaichthyin acanthurids from Monte Bolca accentuate that disparity. The first appearance and great morphological diversification of surgeon fishes and of other acanthuroid families in the Middle Eocene also is suggested by molecular analyses (Clements et al. 2003; Klanten et al. 2004).
A review of the fossil Acanthuridae was given by Tyler and Bannikov (2000). Only four of the fossil genera of acanthurids are from localities other than Monte Bolca: Caprovesposus Danilchenko, 1960 (Early Eocene to Early Miocene of the northwestern Caucasus, Russia, and perhaps from Egypt, see below), Arambourgthurus Tyler, 2000 (Oligocene of Istehbanat, Iran), Marosichthys de Beaufort, 1926 (Miocene of Celebes, Indonesia), and Eonaso Blot, 1984 (unknown age; Antigua, Lesser Antilles). To these we add herein the new genus and species Glarithurus friedmani from the Oligocene of Kanton Glarus (Canton Glaris), Switzerland; it is the first acanthurid taxon known from the Glarus palaeofauna. The new taxon is based upon an acronurus settlement stage, as are several other genera of acanthurids, namely Caprovesposus, Tauichthys Tyler, 1999, and Metacanthurus Blot and Tyler, 1990. Eorandallius Blot and Tyler, 1990, has two species known from adult specimens and one acronurus specimen that has not been determined at the specific level (see Blot and Tyler 1990). Several acronurus specimens were described and referred to Caprovesposus sp. by Gaudant and Rouchy (1986) from the Miocene of Gebel Zeit, Egypt, but the state of their preservation makes the generic allocation uncertain. A very small acronurus specimen, 12.5 mm SL, of an undetermined genus and species, was described from the Miocene of Gavdos Island, Greece, by Gaudant et al. (2005).
Materials and methods
The part and counterpart of the holotype (MB.f. 16519a, b) are kept in the palaeontological collection of the Museum für Naturkunde at the Humboldt-Universität Berlin (see below). They are part of an old collection that was purchased by the museum more than 200 years ago. The fine preparation was done with an HW airbrasive machine, using iron powder Cut 150 of less than 150 μm granularity.
Anatomical terminology and abbreviations
Interneural and interhaemal spaces are numbered according to the vertebra whose neural or haemal spine forms the anterior border of the space, with the first space being between the first and second neural or haemal spines, and the preneural and prehaemal spaces being those in front of the first neural and haemal spines, respectively (e.g., Birdsong et al. 1988; Baldwin and Johnson 1993; Bannikov and Tyler 1995; Tyler and Bannikov 1997; Tyler et al. 2003).
For the radial elements supporting the median fins, we use the terms basal pterygiophore and distal pterygiophore, as has been used in most acanthurid osteological literature; these terms are equivalent to the more recent usage of proximal-middle radial and distal radial, respectively.
an, remains of angular; as, anal-fin spine; asr, anal-fin soft ray; bl, breakage lines of slab; br, branchiostegal rays; brr, remains of branchiostegal rays from other side; cl, cleithrum; ci, circumorbital elements; co, coracoid; de, dermethmoid; dmcr, dorsal marginal caudal ray (procurrent); dpcr, dorsal principal caudal ray; dppt, distal portion of pterygiophore; dr, remains of dentary and teeth; ds, dorsal-fin spine; dsr, dorsal-fin soft ray; ep, epural; fr, frontal; hac, haemaxanal complex; hs, haemal spine; hy, hypural; hyo, hyomandibula; hyr, hyomandibular ridge/crest; le, lateral ethmoid; mx, maxilla; nc, neural crest; ns, neural spine; op, opercle; pcl, postcleithrum; pg, pelvic girdle; ph, parhypural; pl, remains of palatine; plr, pleural ribs; pop, preopercle; pot, posttemporal; ppsr, proximal portion of soft ray; pr, pectoral-fin rays; ps, pelvic-fin spine, pt, pterygiophore; pu, preural centrum; qu, quadrate; sc, scapula; sc, sensory canal; sca, scalpel-like dermal spine; scl, supracleithrum; soc, supraoccipital; sph, sphenotic; sqr, remains of squamation; ssc, supraorbital sensory canal; u, ural centrum; un, uroneural; vmcr, ventral marginal caudal ray (procurrent); vpcr, ventral principal caudal ray; ?, ?? questionable/unidentified elements.
MB.f.: Palaeontological (fish) collection of the Museum für Naturkunde, Leibnitz Institut für Evolutions- und Biodiversitätsforschung at the Humboldt-Universität Berlin; USNM: collections of the former United States National Museum, now in the National Museum of Natural History, Smithsonian Institution, Washington, DC.
Family Acanthuridae Bleeker, 1859
Glarithurus, new genus
Type species: Glarithurus friedmani, new species.
Etymology: Glari, in recognition of the importance of the palaeofauna from the Landesplattenberg Formation in Kanton Glarus; plus the suffix thurus, being the last two syllables in the type genus name Acanthurus, as also used in several other acanthurid generic names.
Diagnosis: Differs from all other acanthurid fishes by having only one anal-fin basal pterygiophore in the first interhaemal space (between the haemal spines of the first and second caudal vertebrae); differs from the other known members of the higher Acanthurinae by the very great depth of the basipterygium (pelvic bone) at the subpelvic keel.
Composition: Presently known only from the type species.
Etymology: In honour of Matt Friedman, palaeoichthyologist at the University of Oxford, who perceptibly recognized an unprepared and misidentified (as the priacanthid Acanus Agassiz, 1838) little Kanton Glarus specimen in the Berlin museum collection as a probable acanthuroid and called it to our attention.
Diagnosis: That of the genus, of which it is the only known representative.
Type locality and horizon: Lower Oligocene (Rupelian) of the Landesplattenberg slate quarry and mine at Engi, near Glarus, Kanton Glarus, Switzerland. Matt Formation, Early Oligocene; 30 MYA (according to Furrer and Leu 1998).
Holotype (and only known specimen): A 29-mm SL acronurus specimen, in the collections of the Museum für Naturkunde, Humboldt-Universität zu Berlin, MB.f. 16519a, b, in part and counterpart.
The jaws and teeth are relatively poorly preserved, and it cannot be determined whether the edges of the teeth are lobed, denticulate, or smooth. There are indications that the dentary is much larger than the articular/angular. The premaxilla is questionably identified in the upper jaw; below and behind this bone is the maxilla, which is probably detached. The quadrate, with a deep indentation posteriorly, is evident behind the lower jaw; the symplectic is not preserved. Behind the upper end of the maxilla is an elongate bone that probably represents the remains of the palatine and perhaps of the endopterygoid. Another prominent elongate bone in the upper region of the snout probably is composed of the dermethmoid and the nasal. In the suspensorium, the hyomandibula and the preopercle are well preserved. The hyomandibula is broad dorsally at its articulation with the skull and tapers ventrally along its contact with the anterodorsal edge of the preopercle. On the lateral surface of the anterodorsal region of the hyomandibula there is a curved and relatively horizontally oriented crest or ridge of bone (hyr, Fig. 3). The preopercle is moderately curved, and there is evidence of a sensory canal. The limits between the opercle and the subopercle are indistinct. Below the anterior end of the preopercle are the basal regions of a row of five branchiostegal rays, and just below them are the remains of a few other branchiostegal rays from the other side. In the lower region of the orbit, the upper edge of the parasphenoid is well preserved, whereas its ventral flange is less precisely indicated but appears to be of moderate depth. Below the parasphenoid is a somewhat upwardly curved arch of bone that is probably the remains of the infraorbital series of bones, and more anteriorly there is a vague indication of a large lachrymal. The upper region of the orbit is well defined by the remains of the lateral ethmoid and the relatively well-preserved frontal, which has some surface sculpturing and sensory canals. The upper anterior region of the frontal has a long prominent serrate ridge. Below the posteroventral region of the frontal there is evidence of the sphenotic, but the other otic bones are indistinct. The upper edge of the supraoccipital and the posterior curvature of the skull are well defined.
The vertically oriented posttemporal is clearly indicated at the rear of the skull just above and in front of the level of the most anterior centra of the vertebral column. Continuing below the posttemporal is the long, strong, vertically upright supracleithrum. The postcleithrum is a long shaft of bone from the rear edge of the cleithrum above the level of the pectoral-fin base to the lower region of the abdominal cavity; it appears to be a single bone. Just behind the lower region of the postcleithrum is a bone that may be the broken-off ventral end of the postcleithrum from the opposite side. The pectoral girdle is relatively well preserved, with a large, long, broad cleithrum and behind which is the large coracoid; just above the dorsal end of the coracoid is the scapula, which has evidence of a foramen and of a prominent knob for articulation with the uppermost pectoral-fin ray. The bases of the pectoral-fin rays are indicated; there are at least 12 rays, but perhaps a few others are not preserved ventrally; the rays become indistinct distally.
The pelvis (basipterygium) is clearly outlined anterior to the pelvic fin, and it is relatively deep in the region of the subpelvic keel (pg, Fig. 3); the region of the posterior process of the pelvis is obscured by the pelvic fin. The pelvic-fin spine from each side is preserved, but the number of soft rays cannot be determined.
This is well preserved, and almost all of its elements are well exposed. There are nine abdominal and 13 caudal vertebrae. The lower regions of the first two abdominal vertebrae are obscured behind the supracleithrum, but their neural spines have a normal position and arrangement. The neural spines of the abdominal vertebrae increase in length from the first to the ninth, and these vertebrae have parapophyses of increasing length from the third to the ninth, with each bearing a pleural rib; the longest ribs extend ventrally to about the middle of the abdominal cavity.
Dorsal fin and dorsal-fin supports
There are nine dorsal-fin spines; the first two are in supernumerary association on the first basal pterygiophore. Although the first spine (ds I, Fig. 3) is short, it clearly protrudes dorsally above the profile of the body; the anterior edge of the first spine is situated along the upper anterior bifurcation of a major fracture line in the matrix of the specimen. The third to the ninth spines are supported on individual basal pterygiophores. Only a few of the more anterior of the soft-dorsal-fin rays have much of their lengths preserved, but there are at least 14 fin rays and probably others that are not evident more posteriorly. There may be the remains of distal pterygiophores between the bases of some of the rays and their basal pterygiophores.
The first dorsal-fin basal pterygiophore is the largest of the series and is situated in the preneural space, with its lower region supported between the anterior edge of the first neural spine and the rear of the skull. The surface of the anterodorsal edge of the first dorsal pterygiophore has a deep indentation into which the base of the first dorsal-fin spine would have rotated in erection; there are two knob-like structures on the upper lateral surface of the pterygiophore that help support the first two spines (pt 1, Fig. 3). The first and second interneural spaces each accommodate a single basal pterygiophore, the third interneural space is vacant (no ventral shaft of a dorsal-fin basal pterygiophore present), and each of the fourth to the tenth interneural spaces accommodates a single basal pterygiophore. More posteriorly, each interneural space accommodates initially two and then three basal pterygiophores before the last of the series of dorsal-fin basal pterygiophores becomes incomplete. The neural spines of the first six caudal vertebrae are about as long as that of the last (ninth) abdominal vertebra, whereas the neural spines of the seventh to the tenth caudal vertebrae are of progressively decreasing length. The neural spine of the 11th caudal vertebra (Pu3) is elongate, reaching dorsally to about the level of the distal ends of the epurals. The neural process of the 12th caudal vertebra (Pu2) is a very low crest, slightly lower even than the short neural spine of the 10th caudal vertebra (Pu4).
Those of the caudal vertebrae are long and strong in the region supporting the anal fin; those of the first five caudal vertebrae are somewhat longer than their corresponding neural spines. The haemal spines of the sixth and seventh caudal vertebrae are of about the same size as the corresponding neural spines, whereas the haemal spines of the eighth and ninth caudal vertebrae are significantly shorter than their corresponding neural spines. This, however, may be an artefact, due to their incomplete preservation. The haemal spine of the 10th caudal vertebra (Pu4) is poorly preserved, but it is apparently somewhat longer than the corresponding neural spine. The haemal spines of the 11th and 12th caudal vertebrae (Pu3 and Pu2) are poorly preserved, but they clearly are very long, reaching distally to the level of the lower end of the hypural plate, and they are apparently autogenous.
Anal-fin and anal fin supports
There are three anal-fin spines, each with a serrate anterior edge and a serrate ridge along the lateral surface. The first two spines are in supernumerary association on the first basal pterygiophore. The first spine is short, but it clearly protrudes ventrally below the profile of the body. The second spine is sturdy and about twice as long as the first spine. The third spine is broken in about the middle of its length, and it is slightly longer than the second spine; the base of the third spine clearly articulates with the posteroventral end of the first basal pterygiophore. The full lengths of most of the soft-anal-fin rays are not exposed, but there are at least 13 fin rays and probably others that are not evident more posteriorly. There may be remains of distal pterygiophores between the bases of some of the rays and their basal pterygiophores.
The first anal-fin basal pterygiophore (hac, Fig. 3) is the largest of the series and is situated in the prehaemal space, with the posterodorsal edge of its shaft being supported along the anteroventral edge of the haemal spine of the first caudal vertebra. The surface of the anteroventral edge of the first anal pterygiophore has a deep indentation into which the base of the first anal-fin spine would have rotated in erection; there are two knob-like structures on the lower lateral surface of the pterygiophore that help support the first two spines (the more anterior of these, for the first spine, is less distinct than the other). There is a single anal-fin basal pterygiophore situated in the first interhaemal space, with its dorsal tip in contact with the anteroventral edge of the haemal spine of the second caudal vertebra. The second through fifth interhaemal spaces each accommodate two anal-fin basal pterygiophores, whereas the sixth space accommodates three basal pterygiophores; more posteriorly, the last of the series of anal-fin basal pterygiophores is incomplete.
This region (Fig. 4) is well preserved, with a terminal centrum (Pu1 + U1) bearing a long and broad uroneural, a parhypural and five separately articulated hypurals; the uppermost (fifth) hypural is a rod-like element situated between the distal regions of the uroneural and the fourth hypural. There are three long and rod-like epurals, except that the first element is incomplete distally. There are 16 principal caudal-fin rays, with five procurrent rays along the ventral margin of the fin and at least one (and probably three) procurrent ray(s) in the less-well-preserved dorsal margin of the fin. The distal ends of many of the branched principal rays are indistinct, but the fin appears to be slightly concave.
The remains of more-or-less obliquely vertical elongate scales are preserved in many places on the flank of the body; however, the scales are relatively poorly preserved, and we can only estimate that their lengths are about five or six times their widths. The elongate, scalpel-like dermal spine (sca, Figs. 3, 4) on the caudal peduncle is situated along the upper half of the centra from the middle of the Pu4 centrum to the front of the terminal centrum (Pu1 + U1); in life, this folding spine would be erectable from its posterior region of attachment to the body, thus forming a formidable sharp piercing weapon.
Measurements as a per cent of the 29-mm SL are as follows: head (from premaxilla to estimated position of rear of basioccipital) 38%; body depth at anal-fin origin 71%; caudal peduncle least depth 15%; depth of pelvis at subpelvic keel 22%; greatest width of pectoral girdle (obliquely across front of cleithrum to rear of coracoid) 18%; length of scalpel-like folding spine on caudal peduncle 8%; length of pelvic-fin spine 13%; length of first dorsal-fin spine 5%; length of second dorsal-fin spine 16%; length of ninth dorsal-fin spine 16%; length of first anal-fin spine 6%; length of second anal-fin spine 11%; length of third anal-fin spine 13%.
Comments on diagnostic and other features of interest
In the following discussions, the term higher acanthurin refers to those genera with a slender, folding, scalpel-like dermal spine on the caudal peduncle and a crest anterodorsally on the hyomandibular (the latter character mostly unknown for fossils), comprising the (Paracanthurus Bleeker, 1863 + Zebrasoma Swainson, 1839) + (Acanthurus Forsskål, 1775 + Ctenochaetus Gill, 1885) clade among extant genera (Guiasu and Winterbottom 1993) and the Eocene of Monte Bolca Proacanthurus Blot and Tyler, 1990 (and probably also the Monte Bolca Tauichthys; see Sorbini and Tyler 1998b and Tyler and Bannikov 2000). By contrast, the lower acanthurins are the species of the extant Prionurus Lacépède, 1804, which have large fixed plates on the caudal peduncle (as also found in nasins) and no crest on the hyomandibular. The two clades of four extant genera within what we consider to be the higher acanthurins have been named as distinct tribes in the excellent, myologically based, phylogeny of Winterbottom (1993), but we do not utilize this formal nomenclature because the fossil taxa cannot be properly placed within such finely split categories of the derived clade of those acanthurids with a folding, scalpel-like, caudal peduncle spine and a hyomandibular crest. In fact, most fossil species of acanthurids are known from only one or very few specimens and the conditions of the caudal peduncle armature and of the anterodorsal region of the hyomandibula are unknown at present for many of them, so four monotypic genera cannot yet be assigned to either the higher or lower acanthurins. The phylogeny of the acanthuroids is documented in Tyler et al. 1989, Winterbottom 1993, Winterbottom and McLennan 1993, Guiasu and Winterbottom 1993, Tyler 2000, 2005a, b, and Tyler and Bannikov 2005.
Table 1 summarizes the character states of the six morphological features discussed below in all of the genera of the four subfamilies of Acanthuridae and in the two outgroup families.
First interhaemal space with single basal pterygiophore
Except for Glarithurus friedmani, all other taxa of the Acanthuridae, both fossil and extant, have at least two anal-fin basal pterygiophores situated in the first interhaemal space between the haemal spines of the first and second caudal vertebrae (for skeletal illustrations documenting the following analysis, see especially Blot 1984; Blot and Tyler 1990; Tyler et al. 1989; Tyler and Bannikov 2000; Tyler 2000, 2005a, b, and their contained references). The vast majority of the extant and fossil taxa of the subfamily Acanthurinae have two anal basal pterygiophores in the first interhaemal space, but three basal pterygiophores are present in the first interhaemal space in Tylerichthys milani Blot and Tyler, 1990 and in Pesciarichthys punctatus Blot and Tyler, 1990, both from the Eocene of Monte Bolca, as well as in two species of the extant genus Acanthurus, A. sohal (Forsskål, 1775) and A. lineatus (Linnaeus, 1758). This increase in the number of basal pterygiophores is usually associated with an increasingly forward positioning of the anal-fin origin under the abdominal cavity, and it is most strikingly evident in the taxa of the subfamily Nasinae. In that subfamily there are four or five anal basal pterygiophores in the first interhaemal space in the taxa of the Eocene of Monte Bolca Sorbinithurus Tyler, 1999 and in the Oligocene of Iran Arambourgthurus, whereas the extreme forward positioning of the anal-fin origin in the many species of the extant Naso Lacépède, 1801 provides room for seven pterygiophores in this space. The anal-fin region in two other fossil genera of nasins is incomplete; therefore, the number of basal pterygiophores in the first interhaemal space is unknown in the Miocene of Celebes Marosichthys and in the Antilles Eonaso, which is of uncertain age but probably not Eocene. In the two exclusively fossil and probably basal subfamilies of Acanthuridae that comprise an unresolved trichotomy with the acanthurin + nasin clade, there are two anal basal pterygiophores in the first interhaemal space in Gazolaichthys Blot & Tyler, 1990 (Gazolaichthyinae), in which the anal-fin origin is not positioned far forward, but four pterygiophores in this space in Padovathurus Tyler, 2005 (Padovathurinae), in which the anal origin is far forward. As documented by Blot & Tyler (1990) for the extant taxa of acanthurids, in which numerous specimens were examined of many species, there is no known intraspecific variability in the number of pterygiophores in the first interhaemal space. Thus, it is evident that the condition of having a single pterygiophore in the first interhaemal space of Glarithurus friedmani is unique (Figs. 3, 5, 6, 7).
The Zanclidae + Massalongiidae is the immediate outgroup of the Acanthuridae, and both the fossil and extant taxa of these two families have two basal pterygiophores in the first interhaemal space (see Blot and Voruz 1970, 1974 for the Eocene of Monte Bolca Eozanclus Blot & Voruz, 1970; Tyler et al. 1989 for the extant Zanclus Cuvier, 1831; and Tyler & Bannikov 2005 for the Eocene of Monte Bolca Massalongius Tyler & Bannikov, 2005). Because Glarithurus friedmani is a member of the higher acanthurins (by virtue of having a slender caudal peduncle spine rather than fixed plates and by having a crest on the anterodorsal surface of the hyomandibula), it is certain that the single pterygiophore in the first interhaemal space is a derived reduction.
In Glarithurus friedmani the dorsal end of the single basal pterygiophore in the first interhaemal space articulates with the anterior edge of the distal end of the haemal spine of the second caudal vertebra; thus, it corresponds in position to the more posterior of the two basal pterygiophores in this space in most other acanthurins (sequentially the third basal pterygiophore). G. friedmani does not have a basal pterygiophore that corresponds in position to the more anterior of the two pterygiophores (sequentially the second basal pterygiophore) in this space that is found in all other acanthurids. Among all other acanthurids, the dorsal end of the more anterior pterygiophore in the first interhaemal space articulates with the posterior edge of the distal end of the haemal spine of the first caudal vertebra.
Depth of pelvis
In an osteological analysis of the relationships of extant acanthurid genera, Guiasu & Winterbottom (1993) documented that the depth of the pelvis (basipterygium), as measured more-or-less vertically at the subpelvic keel (the anteroventral, or iliac, process in front of the pelvic fin) and expressed as a percentage of the length of the pelvis, is relatively deep in the extant Nasinae (16%) and in the Zanclus (17–19%) and Luvarus Rafinesque, 1810 (53%) extant outgroups, and it represents the plesiomorphic condition. By contrast, the depth-to-length ratio is substantially lower in the extant Acanthurinae: it is 8% in the lower acanthurin Prionurus; and among the higher acanthurins it is 8–10% in Paracanthurus and Zebrasoma, 7% in Acanthurus, and 6% in Ctenochaetus. The far more numerous genera of fossil acanthurids are only partially in conformity with the Guiasu and Winterbottom (1993) hypothesis: of the four fossil genera of Nasinae, the subpelvic keel depth is 12% in Marosichthys, 13% in Arambourgthurus, and 18% in Sorbinithurus; but it is only 10% in Eonaso. Moreover, most of the numerous genera of fossil Acanthurinae (mostly from the Eocene of Monte Bolca) also have a relatively deep pelvis, with ratios ranging from 12 to 16%, or even deeper in Metaspisurus Blot & Tyler, 1990 (18%) and Acanthuroides Blot & Tyler, 1990 (30%), whereas some taxa have a relatively slender pelvis, such as Tauichthys (7–8%), Caprovesposus (9%), and Metacanthurus (11%). Furthermore, the higher acanthurin Proacanthurus from Monte Bolca is a genus with a relatively large number of species, and it has subpelvic keel depths ranging from shallow to deep: 7% in P. elongatus Blot & Tyler, 1990; 10% in P. ovalis (Agassiz, 1838); 12% in P. tenuis (Agassiz, 1835); and 15% in P. bonatoi Blot & Tyler, 1990. There obviously is much homoplasy in the depth of the pelvis, and it remains to be seen whether the relatively slender pelvis in some fossil taxa is a derived condition obtained independently of that of the extant acanthurins (see Tyler & Sorbini 1998, and Tyler 1999, 2000, 2005b for additional data and analysis regarding pelvis depth).
In G. friedmani the pelvis has a relatively deep plesiomorphic condition of 22%. Based upon G. friedmani having a folding spine on the caudal peduncle and an anterodorsal crest on the hyomandibular, it is a member of the higher acanthurin clade that presently is known to include Proacanthurus and four extant genera (Paracanthurus + Zebrasoma) + (Acanthurus + Ctenochaetus). In Proacanthurus the pelvic depth is 7–15%, and in the four extant genera it is 6–10%. Thus, G. friedmani has a much deeper and more plesiomorphic pelvic depth than in any other taxon in its higher acanthurin clade, but it remains to be determined whether that greater depth is an ancestral feature of this clade or an independent reversal because of the considerable homoplasy of this feature.
We note that in the Monte Bolca Tauichthys there is evidence that a folding spine on the caudal peduncle may be present in T. aspesae Tyler & Bannikov, 2000, which indicates that Tauichthys is a probable member of the higher acanthurin clade (see discussion of hyomandibular crest, below). Both species of Tauichthys differ from G. friedmani by having very shallow pelvic depths (7–8%), which is the derived condition found in the extant taxa of the higher acanthurins, and in several other important features (e.g., dorsal-fin spines reduced to four).
Tenth interneural space with a single basal pterygiophore
In most acanthurids the 10th interneural space accommodates the ventral shafts of two, or rarely three, dorsal-fin basal pterygiophores. This position is often the place of transition between more anterior interneural spaces having a single basal pterygiophore present and those more posteriorly with two present (in Naso and a few related genera the transition between one versus two pterygiophores per interneural space is more anterior, as far forward as the sixth space; the same references given to support the preceding discussion of anal-fin pterygiophore placement are applicable here for dorsal-fin pterygiophore placement). But whether the transition to two pterygiophores per space occurs at the 10th space or more anteriorly, the following genera of fossil and extant acanthurids have two pterygiophores (or three as indicated) associated with the 10th space: among extant genera of acanthurins and nasins, all species of Acanthurus (A. sohal with three), Naso, and Ctenochaetus, and in Prionurus (P. punctatus Gill, 1862); among fossil genera, all species of Proacanthurus, Metacanthurus, Eorandallius, Acanthuroides, Lehmanichthys Blot & Tyler, 1990, Pesciarichthys, Tylerichthys, Eonaso, Tauichthys, Protozebrasoma Sorbini & Tyler, 1998, and Sorbinithurus; there are three in the 10th space in Arambourgthurus; in the two more basal subfamilies of acanthurids, the fossil gazolaichthyins and padovathurins, there are two in the 10th space in Padovathurus and one in Gazolaichthys; and among the zanclid + massalongiids outgroup to the acanthurids there are two in the 10th space in Eozanclus, three in Zanclus, and one in Massalongius.
By contrast, only a few acanthurid taxa (mostly extant) have a single basal pterygiophore accommodated in the 10th interneural space: among extant taxa all species of Zebrasoma and Paracanthurus and in Prionurus scalprum Cuvier & Valenciennes, 1835; and among fossils only Metaspisurus, Caprovesposus, and Glarithurus. In one fossil genus, Marosichthys, the 10th space is not preserved.
Because nasins, padovathurins, and the zanclid outgroup have at least two pterygiophores in the 10th space, it is most parsimonious to interpret a single pterygiophore in this position as a derived condition in acanthurids and independent of that in Massalongius and Gazolaichthys. Among higher acanthurins, the derived condition is shared only by Glarithurus and the Paracanthurus + Zebrasoma clade, an indication that G. friedmani may be more closely related to that clade (and especially to Paracanthurus, with nine dorsal spines, rather than to Zebrasoma, with the greatly reduced number of four or five dorsal spines) than to the Acanthurus + Ctenochaetus clade. However, without knowing the dentition and many other features of the jaws and hyoid apparatus in G. friedmani, such assessment of its relationships within the higher acanthurins will remain speculative.
Number of dorsal-fin spines
Guiasu and Winterbottom (1993) documented that among extant acanthurids the lowest number of dorsal-fin spines, namely the four or five spines in Zebrasoma and the five of some species of Naso, are independently derived conditions. The derived condition of much reduced numbers of dorsal spines is also found in several taxa from the Eocene of Monte Bolca: four spines in Tauichthys padremenini Tyler 1999 and in T. aspesae; five spines in Tylerichthys nuchalis (Agassiz 1835); and five spines in Protozebrasoma bloti Sorbini & Tyler 1988a. There are also five spines in the Antillean Eonaso of uncertain age. Which number of dorsal spines between six and nine is the ancestral acanthurid plesiomorphic condition remains to be determined (Sorbini & Tyler 1998a, b; Tyler 1999). It is reasonable to assume, however, that Glarithurus, with nine dorsal spines, is probably more closely related to some of those genera with nine (among extant genera Acanthurus, Paracanthurus, Prionurus; among fossil genera Proacanthurus, Metacanthurus, Caprovesposus, Gazolaichthys) or eight (the extant Ctenochaetus and the fossil Pesciarichthys) dorsal spines. Among these genera, only Acanthurus, Paracanthurus, Ctenochaetus, and Proacanthurus share with Glarithurus the derived folding, caudal peduncle spine and hyomandibular crest conditions that define the higher acanthurins, but within this clade the position of Glarithurus is not clarified by the number of dorsal-fin spines.
Folding, scalpel-like spine on caudal peduncle
It is fortunate that the long, scalpel-like, dermal spine on the caudal peduncle is preserved in the single specimen of G. friedmani because the caudal peduncle armature, whether fixed broad plates or a slender, scalpel-like, folding spine, is preserved in only a minority of the specimens of those fossil species known on the basis of numerous specimens (Sorbini and Tyler 1998b). A folding spine is the derived condition (see Winterbottom 1971 for mechanism), and its presence is sufficient to assure the proper placement of G. friedmani among the higher acanthurins; moreover, this conclusion is further supported by a feature of the hyomandibula discussed below.
Guiasu and Winterbottom (1993) documented two derived features that supported a terminal clade of four extant genera (Paracanthurus + Zebrasoma) + (Acanthurus + Ctenochaetus): a folding, caudal peduncle spine and a crest or ridge along the anterodorsal region of the lateral surface of the hyomandibula. This crest is evident in G. friedmani; it is somewhat curvaceous but basically horizontally oriented.
We note that, with a few exceptions, there is no data regarding a hyomandibular crest or ridge in the descriptions and reconstructions of fossil acanthurids; in reconstructions the hyomandibula is mostly shown in peripheral outline with little or no indication of surface features.
One of the exceptions is the reconstruction of the only known specimen of Tauichthys aspesae in Tyler & Bannikov (2000). That reconstruction clearly shows a relatively horizontal crest in the anterodorsal region of the hyomandibula, even though this crest was not mentioned in the description. Based upon a pigmentation pattern on its caudal peduncle, Tyler and Bannikov (2000) proposed that T. aspesae probably has a slender, folding, caudal peduncle spine. We suggest herein that the definite presence of a hyomandibular crest in T. aspesae places the species within the higher acanthurin terminal clade of taxa, and because the other members of the higher acanthurin clade have a folding, caudal peduncle spine, it supports the interpretation that T. aspesae also probably has a folding spine. On this basis, we list Tauichthys among the higher acanthurins in Table 1.
The others exceptions are that the original description of Protozebrasoma bloti by Sorbini & Tyler (1998a) and the redescription of Marosichthys huismani (de Beaufort, 1926) by Tyler (1997) both specifically mentioned that a hyomandibular crest is absent. The absence of this crest in Marosichthys is unremarkable because many derived features place it among the Nasinae (Tyler 2000), of which none are known to have a hyomandibular crest. However, it is the lack of this crest in Protozebrasoma that leads us to place it among the lower acanthurins in Table 1 based upon the rational that it has at least one of the two features characteristic of this category even if its caudal peduncle armature is unknown; our placement predicts that Protozebrasoma will eventually be shown to have fixed plates rather than a scalpel spine.
The width of the pectoral girdle, measured obliquely from the anterior edge of the cleithrum to the posterior edge of the coracoid, has been shown to be especially great in many acronurus stage specimens of both fossil and extant species (Tyler 1999). For example, the widths of the pectoral girdle in the acronurus stage holotypes of the two species of Tauichthys are 19–20%, whereas the widths in adults of both fossil and extant taxa are about 9–15%. The 18% width of this girdle in G. friedmani is one of several features indicating that the specimen is an acronurus stage. However, for some acronurus stage fossils of other taxa the pectoral width is not especially great, perhaps indicating that the specimen had already settled to the substrate and begun its transformation into a juvenile; examples of this are the 11% width in the acronurus stage of a specimen of Eorandallius sp. from Monte Bolca and the 13% width in a specimen of Caprovesposus parvus Danilchenko, 1960 from the Oligocene of Russia.
Prominent serrations are present on many of the head bones, the pelvic-fin spines, the second dorsal-fin spines and the anal-fin spines of acronurus stage specimens of extant species (see Johnson and Washington 1987). Serrations on numerous bones and spines have also been found on fossil acronurus specimens. They are best known on the many specimens of Caprovesposus parvus described by Bannikov & Tyler (1992), in which serrations are recorded on the dentary, frontal, mesethmoid, preopercle, pelvis, and the second dorsal-fin and anal-fin spines. All of the other fossil species with acronurus stage specimens also have at least some serrate bones. In the case of G. friedmani, the only skull bone with prominent serrations is the frontal, and this condition of relatively few bones being serrate may indicate that the specimen had already settled to the substrate and was losing its acronurus features in the process of transformation into a juvenile. The anal spines in G. friedmani have serrate anterior edges and equally serrate lateral ridges along their lengths.
The scales of pelagic, acronurus stage larvae are more-or-less vertically oriented, narrow, and very elongate (e.g., Randall 1961; Johnson and Washington 1987; Frederich et al. 2010). In the 29-mm SL specimen of Glarithurus friedmani, the scales, although obliquely vertical in orientation, are not as long and slender as in fully acronurus stages of extant taxa, indicating that the scales of G. friedmani were in the process of being resorbed and replaced by the smaller and more rounded basal plates that are typical of juveniles.
The second dorsal-fin and second anal-fin spines in acanthurid larval stages are often very elongate (Leis and Rennis 1983; Leis and Richards 1984; Johnson and Washington 1987; Ozawa 1988; Tyler et al. 1989), and these two spines often remain elongate into at least the early acronurus stage. Among the known fossil acronurus stage specimens, the second dorsal and anal spines are elongate only in the single specimens (25.3 and 28.5 mm SL) representing the holotypes of Tauichthys padremenini and T. aspesae. These two spines are not elongate in any of the numerous specimens of Caprovesposus parvus (12.8–29.6 mm SL) (see Bannikov & Tyler 1992) nor in the single late acronurus specimens of Metacanthurus veronensis Blot & Tyler, 1990 (25.6 mm SL) and Eorandallius sp. (23.0 mm SL) (see Blot & Tyler 1990). The absence of elongation of the second dorsal and anal spines in G. friedmani is in conformity with the supposition that it is a very late acronurus stage that had already settled to the substrate and was well along in its transformation into a juvenile.
All extant acronurus larvae originate from spawning on reefs; however, according to Furrer and Leu (1998:116–118), the marl slates from Landesplattenberg–Engi were deposited in the offshore section of a quiet bay that was not very deep, and there are no indications of coral reefs. There probably was a progressively more structured delta with a rocky coastline; therefore, it is difficult to reconcile the presence of acronurus larvae in such an area, even if such larvae are very rare. In extant habitats (e.g., the Hawaiian chain) it has been reported that these larvae become trapped by gyrals and transported as far as 20–50 km away from the shoreline (Sale 1970). Nevertheless, although it is not known how they eventually escape from the gyrals, they return to the reefs and shoreline before settlement, which is approximately the developmental state of the fossil acronurus specimen described herein.
Glarithurus friedmani, from the Oligocene of Kanton Glarus, Switzerland, is shown to be unique among all other acanthurids, both fossil and extant, by having only one anal-fin basal pterygiophore situated in the first interhaemal space (versus two or more in all others). Because G. friedmani has a slender, folding spine on the caudal peduncle and a crest on the anterodorsal region of the hyomandibula, it is a member of the clade of higher acanthurins that includes Proacanthurus from the Eocene of Monte Bolca (and probably also Tauichthys from Monte Bolca) and four extant genera: (Paracanthurus + Zebrasoma) + (Acanthurus + Ctenochaetus). Within its higher acanthurin clade, G. friedmani is unique in the great depth of its pelvis at the subpelvic keel, which is a plesiomorphic condition. The holotype and only known specimen is a late acronurus stage that had already begun to lose some of the typical presettlement pelagic features and to transform into a benthic juvenile.
Baldwin, C. C., & Johnson, G. D. (1993). Phylogeny of the Epinephelinae (Teleostei: Serranidae). Bulletin of Marine Science, 52(1), 240–283.
Bannikov, A.F. & Tyler, J.C. (1992). Caprovesposus from the Oligocene of Russia: The pelagic acronurus presettlement stage of a surgeonfish (Teleostei: Acanthuridae). Proceedings of the Biological Society of Washington, 105(4), 810–820.
Bannikov, A. F., & Tyler, J. C. (1995). Phylogenetic revision of the fish families Luvaridae and †Kushlukiidae (Acanthuroidei), with a new genus and two new species of Eocene luvarids. Smithsonian Contributions to Paleobiology, 81, 1–45.
Birdsong, R. S., Murdy, E. O., & Pezold, F. L. (1988). A study of the vertebral column and median fin osteology in gobioid fishes with comments on gobioid relationships. Bulletin of Marine Science, 42, 174–214.
Blot, J. (1984). Proposition d’une representation schematique des relations entre le squelette axial et le squelette interne des nageoires impaires chez les teleosteens fossils et actuels. Cybium, 8(4), 19–30.
Blot, J., & Tyler, J. C. (1990). New genera and species of fossil surgeon fishes and their relatives (Acanthuroidea, Teleostei) from the Eocene of Monte Bolca, Italy, with application of the Blot formula to both fossil and Recent forms. Studi e Ricerche sui Giacimenti Terziari di Bolca, Museo Civico di Storia Naturale di Verona, 6, 13–92.
Blot, J., & Voruz, C. (1970). Les poissons fossils du Monte Bolca. La famille des Zanclidae. Memorie del Museo Civico di Storia Naturale di Verona, 18, 31–42.
Blot, J. & Voruz, C. (1974). La famille des Zanclidae. Studi e Ricerche sui Giacimenti Terziari di Bolca, Museo Civico di Storia Naturale di Verona, 2, 233–271 (5 pls).
Clements, K. D., Gray, R. D., & Choat, J. H. (2003). Rapid evolutionary divergences in reef fishes of the family Acanthuridae (Perciformes: Teleostei). Molecular Phylogenetics and Evolution, 26(2), 190–201.
Frederich, B., Lecchini, D., & Vandewalle, P. (2010). Evidence of an original scale development during the settlement phase of a coral reef fish (Acanthurus triostegus). Journal of Applied Ichthyology, 26(2), 176–178.
Furrer, H. & Leu, U. B. (1998). Der Landesplattenberg Engi. Forschungsgeschichte, Fosslien und Geologie. Selbstverlag, Stiftung Landesplattenberg Engi, Engi.
Gaudant, J. & Rouchy, J.-M. (1986). Râs Dib: un nouveau gisement de poissons fossils du Miocène moyen du Gebel Zeit (golfe de Suez, Égypte). Bulletin du Museum National d’Histoire Naturelle (Paris), 4 em, série 8, section C, 4, 463–481.
Gaudant, J., Tsaparas, N., Antonarakou, A., Drinia, H., & Dermitzakis, M. D. (2005). The Tortonian fish fauna of Gavdos Island (Greece). Comptes Rendus Palevol, 4(8), 687–695.
Guiasu, R. C., & Winterbottom, R. (1993). Osteological evidence for the phylogeny of Recent genera of surgeonfishes (Percomorpha, Acanthuridae). Copeia, 1993(2), 300–312.
Johnson, G. D., & Washington, B. B. (1987). Larvae of the Moorish idol, Zanclus cornutus, including a comparison with other larval acanthuroids. Bulletin of Marine Science, 40(3), 494–511.
Klanten, S. O., Herwerden, L., van Choat, J. H., & Blair, D. (2004). Patterns of lineage diversification in the genus Naso (Acanthuridae). Molecular Phylogenetics and Evolution, 32(1), 221–235.
Leis, J. M., & Rennis, D. S. (1983). The larvae of Indo-Pacific coral reef fishes. Sydney: New SouthWales University Press.
Leis, J. M. & Richards, W. J. (1984). Acanthuroidei: development and relationships. In H. G. Moser, W. J. Richards, D. M. Cohen, M. P. Fahay, A. W. Kendall Jr & S. L. Richardson (Eds.) Ontogeny and systematics of fishes, vol 1 (pp. 547–551). USA: American Society of Ichthyologists and Herpetologists, Special Publication.
Nelson, J.S. (2006). Fishes of the world. (4th ed). Hoboken: Wiley.
Ozawa, M. (1988). An atlas of the early stage fishes in Japan. Acanthuroidei. Tokyo: Tokai University Press.
Randall, J. E. (1955). An analysis of the genera of surgeon fishes (Family Acanthuridae). Pacific Science, 9(3), 359–367.
Randall, J. E. (1961). A contribution to the biology of the convict surgeonfish of the Hawaiian Islands, Acanthurus triostegus sandvicensis. Pacific Science, 15(2), 215–272.
Sale, P. F. (1970). Distribution of larval Acanthuridae off Hawaii. Copeia, 1970(4), 765–766.
Sorbini, L., & Tyler, J. C. (1998a). A new genus and species of Eocene surgeon fish (Acanthuridae) from Monte Bolca, Italy, with similarities to the Recent Zebrasoma. Studi e Ricerche sui Giacimenti Terziari di Bolca, Museo Civico di Storia Naturale di Verona, 7, 7–19.
Sorbini, L., & Tyler, J. C. (1998b). A new species of the Eocene surgeon fish genus Pesciarichthys from Monte Bolca, Italy, with comments on caudal peduncle armature and supraneurals in acanthurids. Studi e Ricerche sui Giacimenti Terziari di Bolca, Museo Civico di Storia Naturale di Verona, 7, 21–34.
Tyler, J. C. (1970). Osteological aspects of interrelationships of surgeon fish genera (Acanthuridae). Proceedings of the Academy of Natural Sciences of Philadelphia, 122(2), 87–124.
Tyler, J. C. (1997). The Miocene fish Marosichthys, a putative tetraodontiform, actually a perciform surgeon fish (Acanthuridae) related to the Recent Naso. Beaufortia, 47(1), 1–10.
Tyler, J. C. (1999). A new genus and species of surgeon fish (Acanthuridae) with four dorsal-fin spines from the Eocene of Monte Bolca, Italy. Studi e Ricerche sui Giacimenti Terziari di Bolca, Museo Civico di Storia Naturale di Verona, 8, 257–268.
Tyler, J. C. (2000). Arambourgthurus, a new genus of hypurostegic surgeonfish (Acanthuridae) from the Oligocene of Iran, with a phylogeny of the Nasinae. Geodiversitas, 22(4), 525–537.
Tyler, J. C. (2005a). Redescription and basal phylogenetic placement of the acanthurid surgeon fish Gazolaichthys vestenanovae from the Eocene of Monte Bolca, Italy (Perciformes; Acanthuroidea). Studi e Ricerche sui Giacimenti Terziari di Bolca, Museo Civico di Storia Naturale di Verona, 11, 97–117.
Tyler, J. C. (2005b). A new genus for the surgeon fish Acanthurus gaudryi De Zigno 1887 from the Eocene of Monte Bolca, Italy, a morphologically primitive basal taxon of Acanthuridae (Acanthuroidea, Perciformes). Studi e Ricerche sui Giacimenti Terziari di Bolca, Museo Civico di Storia Naturale di Verona, 11, 149–163.
Tyler, J. C., & Bannikov, A. F. (1997). Relationships of the fossil and Recent genera of rabbitfishes (Acanthuroidei: Siganidae). Smithsonian Contributions to Paleobiology, 84, 1–35.
Tyler, J. C., & Bannikov, A. F. (2000). A new species of the surgeon fish genus Tauichthys from the Eocene of Monte Bolca, Italy (Perciformes, Acanthuridae). Bollettino del Museo Civico di Storia Naturale di Verona, 24, 29–36.
Tyler, J. C., & Bannikov, A. F. (2005). Massalongius, gen & fam. nov., a new clade of acanthuroid fishes (Perciformes, Acanthuroidea) from the Eocene of Monte Bolca, Italy, related to the Zanclidae. Studi e Ricerche sui Giacimenti Terziari di Bolca, Museo Civico di Storia Naturale di Verona, 11, 75–95.
Tyler, J. C., Johnson, G. D., Nakamura, I., & Collette, B. B. (1989). Morphology of Luvarus imperialis (Luvaridae), with a phylogenetic analysis of the Acanthuroidei (Pisces). Smithsonian Contributions to Zoology, 485, 1–78.
Tyler, J. C., O’Toole, B., & Winterbottom, R. (2003). Phylogeny of the genera and families of zeiform fishes, with comments on their relationships with tetraodontiforms and caproids. Smithsonian Contributions to Zoology, 618, 1–105.
Tyler, J. C., & Sorbini, L. (1998). On the relationships of Eonaso, an Antillean fossil surgeon fish (Acanthuridae). Studi e Ricerche sui Giacimenti Terziari di Bolca, Museo Civico di Storia Naturale di Verona, 7, 35–42.
Winterbottom, R. (1971). Movement of the caudal spine in some surgeonfishes (Acanthuridae, Perciformes). Copeia, 1971(3), 562–566.
Winterbottom, R. (1993). Myological evidence for the phylogeny of Recent genera of surgeonfishes (Percomorpha, Acanthuridae), with comments on the Acanthuroidei. Copeia, 1993(1), 21–39.
Winterbottom, R., & McLennan, D. A. (1993). Cladogram versatility: evolution and biogeography of the acanthuroid fishes. Evolution, 47(5), 1557–1571.
We thank Matt Friedman (University of Oxford) for calling our attention to the specimen that is the focus of the present contribution. Florian Witzmann (Museum für Naturkunde at Humboldt-University Berlin) kindly permitted our initial investigation of the specimen in the Berlin collection and its subsequent loan to us in Darmstadt and Washington; he also provided us with useful information. Markus Brinkmann (Museum für Naturkunde at Humboldt-University Berlin) skillful conducted the detailed airbrasive preparation of the specimen. Eric Milsom (Hessisches Landesmuseum Darmstadt) carefully mended fractures in the specimen when it was in danger of breaking and then consolidated the slab on a layer of polyester resin. Antje Röber (Darmstadt) prepared the stippled original drawings of the holotypic part and the detail of the caudal fin supports. We appreciate the generosity of Jean Gaudant (17, rue du Docteur Magnan, Paris) for providing us with information on the acronurus materials he had studied from the Miocene of Egypt and Greece. We thank G. David Johnson (National Museum of Natural History, Smithsonian Institution, Washington) for making available to us his extensive collection of cleared and counter-stained early life history stages of extant acanthurids, including many acronurus stages. Sandra Raredon (National Museum of Natural History, Smithsonian Institution, Washington) expertly prepared many radiographs of acronurus stage acanthurids for our use. Our several draft manuscripts leading to this publication benefited from the editing of Diane M. Tyler (Silver Spring, Maryland). Two anonymous reviewers provided useful comments.
